kamilib 0.1.2b0

HTR / OCR models evaluation agnostic Python package, originally based on the Kraken transcription system.

KaMI-lib (Kraken Model Inspector)

HTR / OCR models evaluation agnostic Python package, originally based on the Kraken transcription system.

🔌 Installation

Dependencies

Kami requires (see also requirements.txt) :

• Python <=3.8

• Kraken ==3.0.6

• python-Levenshtein==0.12.2

• termcolor==1.1.0

• torch==1.9.0

• torchvision==0.10.0

• Unidecode==1.3.2

• cython

User installation

Use pip to install package:

$ pip install kamilib

Developer installation

1. Create a local branch of the kami-lib project

$ git clone https://gitlab.inria.fr/dh-projects/kami/kami-lib.git

2. Create a virtual environment

$ virtualenv -p python3.7 kami_venv

then

$ source kami_venv/bin/activate

3. Install dependencies with the requirements file

$ pip install -r requirements.txt

4. Run the tests

$ python -m unittest tests/*.py -v

🏃 Tutorial

An “end-to-end pipeline” example that uses Kamilib (written in French) is available at:

Tools build with KaMI-lib

A turn-key graphical interface : KaMI-app

🔑 Quickstart

KaMI-lib can be used for different use cases with the class Kami().

First, import the KaMI-lib package :

from kami.Kami import Kami

The following sections describe two use cases :

• How to compare outputs from any automatic transcription system,

• How to use KaMI-lib with a transcription prediction produced with a Kraken model.

Summary

1. Compare a reference and a prediction, independently from the Kraken engine

2. Evaluate the prediction of a model generated with the Kraken engine

3. Use text preprocessing to get different scores

4. Metrics options

5. Others

1. Compare a reference and a prediction, independently from the Kraken engine

KaMI-lib allows you to compare two strings or two text files by accessing them with their path.

# Define your string to compare.
reference_string = "Les 13 ans de Maxime ? étaient, Déjà terriblement, savants ! - La Curée, 1871. En avant, pour la lecture."

prediction_string = "Les 14a de Maxime ! étaient, djàteriblement, savants - La Curée, 1871. En avant? pour la leTTture."

# Or specify the path to your text files.
# reference_path = "reference.txt"
# prediction_path = "prediction.txt"

# Create a Kami() object and simply insert your data (string or raw text files)
k = Kami([reference_string, prediction_string])

you can retrieve the results as dict with the .board attribute:

print(k.scores.board)

which returns a dictionary containing your metrics (see also Focus on metrics section further):

{'levensthein_distance_char': 14, 'levensthein_distance_words': 8, 'hamming_distance': 'Ø', 'wer': 0.4, 'cer': 0.13333333333333333, 'wacc': 0.6, 'wer_hunt': 0.325, 'mer': 0.1320754716981132, 'cil': 0.17745383867832842, 'cip': 0.8225461613216716, 'hits': 92, 'substitutions': 5, 'deletions': 8, 'insertions': 1}

You can also access a specific metric, as follows:

print(k.scores.wer)

2. Evaluate the prediction of a model generated with the Kraken engine

The Kami() object uses a ground truth (XML ALTO or XML PAGE format only, no text format), a transcription model and an image to evaluate prediction made by the Kraken engine.

Here is a simple example demonstrating how to use this method with a ground truth in ALTO XML:

# Define ground truth path (XML ALTO here)
alto_gt = "./datatest/lectaurep_set/image_gt_page1/FRAN_0187_16402_L-0_alto.xml"
# Define transcription model path
model="./datatest/lectaurep_set/models/mixte_mrs_15.mlmodel"
# Define image
image="./datatest/lectaurep_set/image_gt_page1/FRAN_0187_16402_L-0.png"

# Create a Kami() object and simply insert your data
k = Kami(alto_gt,
         model=model,
         image=image)

To retrieve the results as dict (.board attribute), as use case 1.:

print(k.scores.board)

which returns a dictionary containing your metrics (for more details on metrics see section …):

{'levensthein_distance_char': 408, 'levensthein_distance_words': 255, 'hamming_distance': 'Ø', 'wer': 0.3128834355828221, 'cer': 0.09150033639829558, 'wacc': 0.6871165644171779, 'wer_hunt': 0.29938650306748466, 'mer': 0.08970976253298153, 'cil': 0.1395071670835435, 'cip': 0.8604928329164565, 'hits': 4140, 'substitutions': 238, 'deletions': 81, 'insertions': 89}

Depending on the size of the ground truth file, the prediction process may take more or less time.

Kraken parameters can be modified. You can specify the number of CPU workers for inference (default 3) with the workers parameter and you can set the principal text direction with the text_direction parameter (“horizontal-lr”, “horizontal-rl”, “vertical-lr “, “vertical-rl”. By default Kami uses “horizontal-lr”.).

k = Kami(alto_gt,
         model=model,
         image=image,
         workers=3,
         text_direction="horizontal-lr")

3. Use text preprocessing to get different scores

KaMI-lib provides the possibility to apply textual transformations on the ground truth and the prediction before evaluating them. By doing so, scores can change according to the performance of the model used. This functionality allows a better made by the transcription model. For example, if removing all diacritics improves the scores, it probably means that the model is not good enough at transcribing them. By default no preprocessing is applied.

To preprocess the ground truth and the prediction, you can use apply_transforms parameter from Kami() class.

The apply_transforms parameter receives a character code corresponding to the transformations to be performed :

Character code	Applied transformation
D	remove digits
U	uppercase
L	lowercase
P	remove punctuation
X	remove diacritics

You can combine these options as follows:

k = Kami(
    [ground_truth, prediction],
    apply_transforms="XP" # Combine here : remove diacritics + remove punctuation
    )

It results in a dictionary of more complex scores (use built-in pprint module to create a human readable dict.), as follows:

import pprint

# Get all scores
pprint.pprint(k.scores.board)

{'Length_prediction': 2507,
      'Length_prediction_transformed': 2405,
      'Length_reference': 2536,
      'Length_reference_transformed': 2426,
      'Total_char_removed_from_prediction': 102,
      'Total_char_removed_from_reference': 110,
      'Total_diacritics_removed_from_prediction': 84,
      'Total_diacritics_removed_from_reference': 98,
      'all_transforms': {'cer': 5.81,
                         'cil': 8.38,
                         'cip': 91.61,
                         'deletions': 48,
                         'hamming_distance': 'Ø',
                         'hits': 2312,
                         'insertions': 27,
                         'levensthein_distance_char': 141,
                         'levensthein_distance_words': 73,
                         'mer': 5.74,
                         'substitutions': 66,
                         'wacc': 82.28,
                         'wer': 17.71},
      'default': {'cer': 6.62,
                  'cil': 9.55,
                  'cip': 90.44,
                  'deletions': 59,
                  'hamming_distance': 'Ø',
                  'hits': 2398,
                  'insertions': 30,
                  'levensthein_distance_char': 168,
                  'levensthein_distance_words': 90,
                  'mer': 6.54,
                  'substitutions': 79,
                  'wacc': 79.54,
                  'wer': 20.45},
      'remove_diacritics': {'cer': 6.08,
                            'cil': 8.78,
                            'cip': 91.21,
                            'deletions': 49,
                            'hamming_distance': 'Ø',
                            'hits': 2379,
                            'insertions': 31,
                            'levensthein_distance_char': 152,
                            'levensthein_distance_words': 77,
                            'mer': 6.0,
                            'substitutions': 72,
                            'wacc': 82.05,
                            'wer': 17.94},
      'remove_punctuation': {'cer': 6.37,
                             'cil': 9.25,
                             'cip': 90.74,
                             'deletions': 57,
                             'hamming_distance': 'Ø',
                             'hits': 2330,
                             'insertions': 25,
                             'levensthein_distance_char': 157,
                             'levensthein_distance_words': 86,
                             'mer': 6.31,
                             'substitutions': 75,
                             'wacc': 79.71,
                             'wer': 20.28}}

• The ‘default’ key indicates the scores without any transformations;

• The ‘all_transforms’ key indicates the scores with all transformations applied (here remove diacritics + remove punctuation).

If you have used text preprocessing, for example:

• The ‘remove_punctuation’ key indicates the scores with removed punctuations only;

• The ‘remove_diacritics’ key indicates the scores with removed diacritics only.

4. Metrics options

KaMI provides the possibility to weight differently the operations made between the ground truth and the prediction (as insertions, substitutions or deletions). By default this operations have a weight of 1. You can change these weigthts with the parameters in the Kami() class:

• insertion_cost

• substitution_cost

• deletion_cost

Keep in mind that these weights are the basis for Levensthein distance computations and performance metrics like WER and CER, which can greatly influence final scores.

Example:

k = Kami(
    [ground_truth, prediction],
    insertion_cost=1,
    substitution_cost=0.5,
    deletion_cost=1
    )

Kami() class also provides score display settings :

• truncate (bool) : Option to truncate result. Defaults to False.

• percent (bool) : True if the user want to show result in percent else False. Defaults to False.

• round_digits (str) : Set the number of digits after floating point in string form. Defaults to ‘.01’.

Example :

k = Kami([ground_truth, prediction],
             apply_transforms="DUP",
             verbosity=False,
             truncate=True,
             percent=True,
             round_digits='0.01')

5. Others

For debugging you can pass the verbosity (defaults to False) parameter in the Kami() class, this displays execution logs.

🎯 Focus on metrics

Operations between strings

• Hits: number of identical characters between the reference and the prediction.

• Substitutions: number of substitutions (a character replaced by another) necessary to make the prediction match the reference.

• Deletions: number of deletions (a character is removed) necessary to make the prediction match the reference.

• Insertions: number of insertions (a character is added) necessary to make the prediction match the reference.

for each of these operations, except hits, a cost of 1 is assigned by default.

Distances

• Levensthein Distance (Char.): Levenshtein distance (sum of operations between character strings) at character level.

• Levensthein Distance (Words): Levenshtein distance (sum of operations between character strings) at word level.

• Hamming Distance: A score if the strings’ lengths match but their content is different; Ø if the strings’ lengths don’t match.

Transcription performance (HTR/OCR)

The performance metrics are calculated with the Levenshtein distances mentioned above.

• WER : Word Error Rate, proportion of words bearing at least one recognition error. It is generally between [0, 1.0], the closer it is to 0 the better the recognition. However, a bad recognition can lead to a WER> 1.0.

• CER : Character Error Rate, proportion of characters erroneously transcribed. Generally more accurate than WER. It is generally between [0, 1.0], the closer it is to 0 the better the recognition. However, a bad recognition can lead to a CER> 1.0.

• Wacc : Word Accuracy, proportion of words bearing no recognition error.

• WER Hunt : reproduce the Word Error Rate experiment by Hunt (1990). Same principle as WER computation with a weighting of O.5 on insertions and deletions. This metric shows the importance of customizing the weighting of operations made between strings as it depends heavily on the system and type of data used in an HTR/OCR project. In KaMI-lib, it is possible to modify the weigthts assigned to operations.

Experimental Metrics (metrics borrowed from Speech Recognition - ASR)

• Match Error Rate

• Character Information Lost

• Character Information Preserve

❓ Do you have questions, bug report, features request or feedback ?

Please use the issue templates:

• 🐞 Bug report: here

• 🎆 Features request: here

if aforementioned cases does not apply, feel free to open an issue.

✒️ How to cite

@misc{Kami-lib,
    author = "Lucas Terriel (Inria - ALMAnaCH) and Alix Chagué (Inria - ALMAnaCH)",
    title = {Kami-lib - Kraken model inspector},
    howpublished = {\url{https://gitlab.inria.fr/dh-projects/kami/kami-lib}},
    publisher = {GitLab-inria},
    year = {2021}
}

🐙 License and contact

Distributed under MIT license. The dependencies used in the project are also distributed under compatible license.

Mail authors and contact: Alix Chagué ([e-mail]) and Lucas Terriel ([e-mail])

Special thanks: Hugo Scheithauer ([e-mail])

KaMI-lib is developed and maintained by authors (2021-2022, first version named Kraken-Benchmark in 2020) with contributions of ALMAnaCH at Inria Paris.
