pin 3.9.0

A fast and flexible implementation of Rigid Body Dynamics algorithms and their analytical derivatives

Pinocchio instantiates the state-of-the-art Rigid Body Algorithms for poly-articulated systems based on revisited Roy Featherstone's algorithms. Besides, Pinocchio provides the analytical derivatives of the main Rigid-Body Algorithms, such as the Recursive Newton-Euler Algorithm or the Articulated-Body Algorithm.

Pinocchio was originally designed for robotics applications, but it can be used in other contexts (biomechanics, computer graphics, vision, etc.). It is built upon Eigen for linear algebra and FCL for collision detection. Pinocchio includes a Python interface for fast code prototyping, directly accessible through Conda.

Pinocchio is now at the heart of various robotics software as Crocoddyl, an open-source and efficient Differential Dynamic Programming solver for robotics, the Stack-of-Tasks, an open-source and versatile hierarchical controller framework, or the Humanoid Path Planner, open-source software for Motion and Manipulation Planning.

If you want to learn more about Pinocchio internal behaviors and main features, we invite you to read the related paper and the online documentation or DeepWiki.

If you want to dive into Pinocchio directly, only one single line is sufficient (assuming you have Conda):

conda install pinocchio -c conda-forge

or via pip (currently only available on Linux):

pip install pin

Table of contents

• Table of contents
• Pinocchio main features
• Documentation
• Examples
• Tutorials
• Pinocchio continuous integrations
• Performances
• Ongoing developments
• Installation
  • ROS
• Visualization
• Citing Pinocchio
• Questions and Issues
• Core-dev team
• Credits
• Open-source projects relying on Pinocchio
• Acknowledgments

Pinocchio main features

Pinocchio is fast:

• C++ template library,
• cache friendly,
• support custom scalar type.

Pinocchio is versatile, implementing basic and more advanced rigid body dynamics algorithms:

• forward kinematics and its analytical derivatives,
• forward/inverse dynamics and their analytical derivatives,
• centroidal dynamics and its analytical derivatives,
• computations of kinematic and dynamic regressors for system identification and more,
• full support of closed-loop mechanisms,
• state-of-the-art frictional contact solvers,
• low-complexity constrained articulated body algorithms,
• sparse constrained dynamics and its analytical derivatives,
• full support of multiple-precision floating-point (MPFR) in Python and C++,
• support of modern and open-source Automatic Differentiation frameworks like CppAD or CasADi,
• automatic code generation support is available via CppADCodeGen.

Pinocchio can support description formats:

• URDF format,
• SDF format,
• MJCF format,
• SRDF format,
• programmatically.

Pinocchio is flexible:

• header only,
• template instantiation,
• C++ 11/14/17/20/23 compliant.

Pinocchio is extensible. Pinocchio is multi-thread friendly. Pinocchio is reliable and extensively tested (unit tests, simulations, and real-world robotics applications). Pinocchio is supported and tested on Windows, Mac OS X, Unix, and Linux (see build status here).

Documentation

The online Pinocchio documentation of the last release is available here. A cheat sheet pdf with the main functions and algorithms can be found here.

Examples

In the examples directory, we provide some basic examples of using Pinocchio in Python. Additional examples introducing Pinocchio are also available in the documentation.

Tutorials

Pinocchio comes with a large bunch of tutorials aiming at introducing the basic tools for robot control. Tutorial and training documents are listed here. You can also consider the interactive Jupyter notebook set of tutorials developed by Nicolas Mansard and Yann de Mont-Marin.

Pinocchio continuous integrations

Pinocchio is constantly tested for several platforms and distributions, as reported below:

CI on ROS
CI on Linux via APT
CI on macOS and Windows via Pixi
CI on Linux via Robotpkg

Performances

Pinocchio exploits, at best, the sparsity induced by the kinematic tree of robotics systems. Thanks to modern programming language paradigms, Pinocchio can unroll most of the computations directly at compile time, allowing to achieve impressive performances for an extensive range of robots, as illustrated by the plot below, obtained on a standard laptop equipped with an Intel Core i7 CPU @ 2.4 GHz.

For other benchmarks, and mainly the capacity of Pinocchio to exploit, at best, your CPU capacities using advanced code generation techniques, we refer to the technical paper. In addition, the introspection may also help you to understand and compare the performances of the modern rigid body dynamics libraries.

Ongoing developments

If you want to follow the current developments, you can refer to the devel branch. The devel branch only contains the latest release. Any new Pull Request should be submitted on the devel branch.

Installation

Pinocchio can be easily installed on various Linux (Ubuntu, Fedora, etc.) and Unix distributions (Mac OS X, BSD, etc.). Please refer to the installation procedure.

Conda

You simply need this simple line:

conda install pinocchio -c conda-forge

Docker

docker run --rm -it ghcr.io/stack-of-tasks/pinocchio:devel

ROS

Pinocchio is also deployed on ROS. You may follow its deployment status below.

If you're interested in using Pinocchio on systems and/or with packages that integrate with the ROS ecosystem, we recommend the installation of Pinocchio via the binaries distributed via the ROS PPA. Here, you can install Pinocchio using:

sudo apt install ros-$ROS_DISTRO-pinocchio

This installs Pinocchio with Coal support for collision checking and with Python bindings. You can then use Pinocchio in your ROS packages by:

• Depending on Pinocchio in your package.xml config (<depend>pinocchio</depend>)
• Including Pinocchio via CMake (find_package(pinocchio REQUIRED)) and linking against Pinocchio (target_link_libraries(my_library pinocchio::pinocchio))

We include support and hooks to discover the package for ROS build systems. A ROS 2 example can be found in this repository.

Please note that we always advise including the pinocchio/fwd.hpp header as the first include to avoid compilation errors from differing Boost-variant sizes.

ROS 2 Distro	Build Status
Humble
Jazzy
Kilted
Rolling

Visualization

Pinocchio provides support for many open-source and free visualizers:

• Gepetto Viewer: a C++ viewer based on OpenSceneGraph with Python bindings and Blender export. See here for a C++ example on mixing Pinocchio and Gepetto Viewer.
• Meshcat: supporting visualization in Python and which can be embedded inside any browser.
• Panda3d: supporting visualization in Python and which can be embedded inside any browser.
• RViz: supporting visualization in Python and which can interact with other ROS packages.
• Viser: supporting browser-based visualization in Python, with support for widgets such as sliders and interactive markers.

Many external viewers can also be integrated. For more information, see the example here.

Citing Pinocchio

To cite Pinocchio in your academic research, please consider citing the software paper and use the following BibTeX entry:

@inproceedings{carpentier2019pinocchio,
   title={The Pinocchio C++ library -- A fast and flexible implementation of rigid body dynamics algorithms and their analytical derivatives},
   author={Carpentier, Justin and Saurel, Guilhem and Buondonno, Gabriele and Mirabel, Joseph and Lamiraux, Florent and Stasse, Olivier and Mansard, Nicolas},
   booktitle={IEEE International Symposium on System Integrations (SII)},
   year={2019}
}

And the following one for the link to the GitHub codebase:

@misc{pinocchioweb,
   author = {Justin Carpentier and Florian Valenza and Nicolas Mansard and others},
   title = {Pinocchio: fast forward and inverse dynamics for poly-articulated systems},
   howpublished = {https://stack-of-tasks.github.io/pinocchio},
   year = {2015--2021}
}

Citing specific algorithmic contributions

Pinocchio goes beyond implementing the standard rigid-body dynamics algorithms and results from active research on simulation, learning, and control. Pinocchio provides state-of-the-art algorithms for handling constraints, differentiating forward and inverse dynamics, etc. If you use these algorithms, please consider citing them in your research articles.

• Carpentier, J., Le Lidec, Q. & Montaut, L. (2024, July). From Compliant to Rigid Contact Simulation: a Unified and Efficient Approach. In RSS 2024-Robotics: Science and Systems (RSS 2024).
• Le Lidec, Q., Jallet, W., Montaut, L., Laptev, I., Schmid, C., & Carpentier, J. (2024). Contact models in robotics: a comparative analysis. IEEE Transactions on Robotics.
• Montaut, L., Le Lidec, Q., Petrik, V., Sivic, J., & Carpentier, J. (2024). GJK++: Leveraging Acceleration Methods for Faster Collision Detection. IEEE Transactions on Robotics.
• Sathya, A., & Carpentier, J. (2024). Constrained Articulated Body Dynamics Algorithms. IEEE Transactions on Robotics.
• Montaut, L., Le Lidec, Q., Bambade, A., Petrik, V., Sivic, J., & Carpentier, J. (2023, May). Differentiable collision detection: a randomized smoothing approach. In 2023 IEEE International Conference on Robotics and Automation (ICRA).
• Montaut, L., Le Lidec, Q., Petrik, V., Sivic, J., & Carpentier, J. (2022, June). Collision Detection Accelerated: An Optimization Perspective. In Robotics: Science and Systems (RSS 2022).
• Carpentier, J., Budhiraja, R., & Mansard, N. (2021, July). Proximal and sparse resolution of constrained dynamic equations. In Robotics: Science and Systems (RSS 2021).
• Carpentier, J., & Mansard, N. (2018, June). Analytical derivatives of rigid body dynamics algorithms. In Robotics: Science and Systems (RSS 2018).

Questions and Issues

Do you have a question or an issue? You may either directly open a new question or a new issue or, directly contact us via the mailing list [e-mail].

Core-dev team

The currently active core developers of Pinocchio are:

• Justin Carpentier (Inria): main developer and manager of the project
• Guilhem Saurel (LAAS-CNRS): CI/CD, packaging
• Etienne Arlaud (Inria): core developer
• Wilson Jallet (LAAS-CNRS/Inria): extension of Python bindings, C++ visualization API
• Fabian Schramm (Inria): core developper
• Stéphane Caron (Inria): core developper
• Joris Vaillant (Inria): core developer and project manager
• Megane Millan (Inria): core developer
• Ajay Sathya (Inria): core developer

Credits

In addition to the core dev team, the following people have also been involved in the development of Pinocchio and are warmly thanked for their contributions:

• Nicolas Mansard (LAAS-CNRS): initial project instructor
• Joseph Mirabel (Eureka Robotics): Lie groups and hpp-fcl support
• Antonio El Khoury (Wandercraft): bug fixes
• Gabriele Buondono (LAAS-CNRS): features extension, bug fixes, and Python bindings
• Florian Valenza (Astek): core developments and hpp-fcl support
• Wolfgang Merkt (University of Oxford): ROS integration and support
• Rohan Budhiraja (Inria/LAAS-CNRS): features extension
• Loïc Estève (Inria): Conda integration and support
• Igor Kalevatykh (Inria): Panda3d viewer support
• Matthieu Vigne (Wandercraft): MeshCat viewer support
• Robin Strudel (Inria): features extension
• François Keith (CEA): Windows support
• Sarah El Kazdadi (Inria): multi-precision arithmetic support
• Nicolas Torres Alberto (Inria): features extension
• Shubham Singh (UT Austin): second-order inverse dynamics derivatives
• Sebastian Castro (RAI Institute): Viser visualizer and MeshCat visualizer feature extension
• Lev Kozlov: Kinetic and potential energy regressors
• Simeon Nedelchev: Pseudo inertia and Log-Cholesky parametrization
• Alexy Legrand: Viser color bug fixes
• Pierre Puchaud: Ellipsoid Joint
• Lucas Joseph: Ellipsoid Joint

If you have participated in the development of Pinocchio, please add your name and contribution to this list.

Open-source projects relying on Pinocchio

• Crocoddyl: A software to realize model predictive control for complex robotics platforms.
• TSID: A software that implements a Task Space Inverse Dynamics QP.
• HPP: A SDK that implements motion planners for humanoids and other robots.
• Jiminy: A simulator based on Pinocchio.
• ocs2: A toolbox for Optimal Control for Switched Systems (OCS2)
• TriFingerSimulation: TriFinger Robot Simulation (a Robot to perform RL on manipulation).
• Casadi_Kin_Dyn: IIT Package for generation of symbolic (SX) expressions of robot kinematics and dynamics.
• PyRoboPlan: An educational Python library for manipulator motion planning using the Pinocchio Python bindings.
• RoboPlan: A modern robot motion planning library based on Pinocchio, built in C++ with Python bindings (successor to PyRoboPlan).
• ProxSuite-NLP: A primal-dual augmented Lagrangian solver for nonlinear programming on manifolds.
• Aligator: A versatile and efficient framework for constrained trajectory optimization.
• Simple: The Simple Simulator: Simulation Made Simple.
• LoIK: Low-Complexity Inverse Kinematics.
• PlaCo: Rhoban's planning and control library, featuring task-space inverse kinematics and dynamics high-level API for whole-body control tasks.
• CRISP controllers: Collection of real-time, C++ controllers for compliant torque-based control for manipulators compatible with ros2_control.

Acknowledgments

The development of Pinocchio is actively supported by the Gepetto team @LAAS-CNRS and the Willow team @INRIA.
